7-MAINTENANCE

Workingattachments

NOTICE:Beforeapplyingnewgreaseontheslidingsurfaces,cleanandremovealldirtaccumulationsandforeign

bodies.

Rails-Greasing

Telescopicdipperrails

Rails(1):2

LEEN11T0374AA1

Sideshiftcarriagerails(sideshiftmachines)

Rails(2):2

LEEN11T0374AA2

Stabilizerslipperrails

Rails(3):2

LEEN11T0374AA3

7-37
