Case 695ST - Backhoe Attachment Mechanical Controls Version

3-CONTROLSANDINSTRUMENTS
Backhoeattachmentmechanicalcontrolsversion
WARNING
Unexpectedmachinemovement!
Beforeyouusethebackhoeattachment,makesurethatthemachineisrestingonthestabilizers.
Failuretocomplycouldresultindeathorseriousinjury.
W1326A
Stabilizermechanicalcontrols
Left-handstabilizerleft-handcontrollever
Thisleverhasthreepositions:
Position0:Neutral.Thispositionstopsthemovementof
theleft-handstabilizer.Assoonastheleverisreleased,
itautomaticallyreturnstotheneutralposition0andthe
left-handstabilizerstopsraisingorlowering.
Position1:Theleft-handstabilizerlowers.
Position2:Theleft-handstabilizerrises.
Right-handstabilizerright-handcontrol
lever
Thisleverhasthreepositions:
Position0:Neutral.Thispositionstopsthemovementof
theright-handstabilizer.Assoonastheleverisreleased,
itautomaticallyreturnstotheneutralposition0andthe
right-handstabilizerstopsraisingorlowering.
Position1:Theright-handstabilizerlowers.
Position2:Theright-handstabilizerrises.
NOTE:Toraiseorlowerthetwostabilizersatthesame
time,operatethetwoleverssimultaneously.
NOTICE:Beforemachinetravelorbeforeusingthe
loaderattachment,makesurethestabilizersarecom-
pletelyraised.
Duringroadtravel,thestabilizersmustbecompletely
raisedandimmobilizedwiththepinsprovidedforthat
purpose.
LEEN11T0312AA1
Lockingthestabilizermechanicalcontrols
(specictocertaincountries)
Thepin(1)locatedinfrontofthestabilizercontrollevers,
isusedtolockthestabilizercontrols.
Tolockthecontrols,removethepinfromitshousingand
installitinthespeciallyprovidedholeintheconsole.
NOTICE:Beforeleavingtheoperator’scompartment,un-
dertakinganyroadtravelorworkingwiththebackhoeat-
tachment,placethepininlockingposition.
LEEN11T0313AA2
3-59
