Case 695ST - Manual Auxiliary Hydraulic Tools

10-ACCESSORIES
Manualauxiliaryhydraulictools
WARNING
Equipmentfailurecouldcauseaccidentorinjury!
Useonlyauthorizedauxiliaryhydraulicattachments.Alwaysreadandunderstandthemanualorin-
structionssuppliedbythemanufacturertoavoidinjuryordamage.Understandtheoperationand
safetyinstructionsbeforeyouattach,remove,oroperatetheattachment.
Failuretocomplycouldresultindeathorseriousinjury.
W0231A
Beforeusingauxiliarytools(3),itismandatoryto
proceedasfollows:
1.Placethedirection-of-travelcontrollevertoneutral
position.
2.Placethegearshiftleverintheneutralposition.
3.Lowertheloaderattachmenttotheground.
4.Applytheparkingbraketopreventthemachinefrom
moving.
5.Shutdowntheengine,releaseallpressureinthe
auxiliarycircuit.
6.Placethemanualauxiliaryhydraulictoolswitch(1)in
theOFFposition.
7.Stoptheengine,removetheplugsandconnectthe
toolhosestothecouplingsinfrontofthefueltank.
Coupling(3)isforthehydraulicoilsupplylineand
coupling(2)isforthehydraulicoilreturnline.
8.Starttheengineandplacetheacceleratorknob/lever
infullspeedposition.
9.Placethemanualauxiliaryhydraulictoolswitch(1)in
theONposition(lampon),nowitispossibletouse
thetool.
10.Whenthetoolisnolongerrequired,placethemanual
auxiliaryhydraulictoolswitch(1)backtotheOFF
position(lampoff).
LEEN11T0287BA1
FLOWSELECTION
Itisuptotheoperatortodecidewhichowshould
beusedbyconsultingthemanufacturer’soperating
instructions.Makesuretorespecttheprescribed
delivery.Excessowcandamagesomeequipment.
1.Ifnecessary,adjusttheowregulatoronthechassis
infrontoftherearaxle.ConsultyourDealerforassis-
tance.
LEEN11T0288AA2
10-5
