Case 695ST - Lifting Loads

6-WORKINGOPERATIONS
Liftingloads
CAUTION
IMPROPEROPERATIONOFTHISMACHINECANCAUSEDEATHORSERIOUSINJURY.
Makesurethatyoucomplywiththelocalliftingregulations(ifany).Contactyourdealerformore
details.
Failuretocomplycouldresultinminorormoderateinjury.
C0162A
CAUTION
Avoidinjury!
FollowALLoftheprecautionslistedbelow.
Failuretocomplycouldresultinminorormoderateinjury.
C0125A
Safetyinstructions
NOTE:ThebackhoeisNOTacrane.Forthisreason,alwaysbeverycarefulwhenyouliftaloadwiththebackhoe.
Handlingofhangingloadstocompletetheworkingcycleisallowed,providedthatthemachineisequippedwiththe
relevantoption,providedondemand.Suspendedloadsmustbehandledinstrictcompliancewiththerelevantnational
regulationsandwiththesafetyinstructionsgiveninthismanual.
Theanti-dropvalveslocatedonthecylindersoftheloaderandbackhoeattachment,theliftingloadtablelocatedin
thecab,andthehookonthelinkofthebucketlinkagearesafetydevices.Thelackofoneofthemoradamageditem
makethemachineuntforuse.
Beforehandlingsuspendedloads,checkthatthevalvesdonotshowclearevidenceofdamageoranomalousnoise.
Intheeventanomalousconditionsarefound,contacttheDealer;inthemeantime,donotusethemachineforhandling
suspendedloads.Checkthattheliftingdevice(hooks,chains,etc.)isinperfectconditions,withoutanysignof
excessivewear.Thedevicecanbeusedexclusivelytoliftpartsnotanchoredtotheground.Neveruseitfortowing,
uprootingortearingoperations.Inanycase,complywiththecurrentregulationsinforceasregardscheckingthese
devices(notsuppliedwiththemachine).
Checkthatthesafetyvalvesoperatecorrectly.Apressuresettingcheckmustbecarriedouteverysixmonthsin
accordancewiththemanufacturer’sinstructions.ConsultyourDealer.
NOTICE:Anysafetyvalvesystemdifferentfromtheoneprovidedcannotbeusedtoliftloads.ConsultyourDealer.
Forloadlifting,itismandatorythatthemachineisequippedwithsafetyvalvesappliedonthecylindersofthebackhoe
attachmentandonthecylindersofthestabilizers,withaloadliftingchartcorrespondingtothetypeofmachineand
attachmentsused,andwitharoll-over(anti-tipping)protectionalarm.
Inordertopreventinjuries,donotexceedthenominalloadcapacityofthemachine.Ifthemachineisnotonalevel
surface,theloadcapacityisreduced.Inanycase,alwaysproceedwithextremecare.
Suspendedloadscanrotateandswinginalldirections;therefore,thereisthedangerouspossibilitythattheyhit
personsorthecabofthemachine.Inordertolimitthisdanger,itisabsolutelyrequiredthatallbystandersaremoved
awayfromtheoperatingrangeofthemachineandthattheloadishandledslowly.Intheeventtheloadrotatesor
swingsduringhandling,slowdownuntilthemachinestopsandlowertheloadslowlytotheground;then,correctthe
wayitisslung.
Machinepreparation
NOTE:Inallscenariosthatmultipleimagesappearthe
followingisvalid;FigureAappliestomodelswithanover-
lappingcylinderboom.FigureBappliestomodel580T/
580STwithanin-linecylinderboom.
1.Knowandunderstandeachsignalfromthesignalman
beforeyoustart.
2.Alwaysknowthelocationofallworkersand/orby-
standersinyourworkingarea.
6-41
