6-WORKINGOPERATIONS
4WS
NOTE:Thetotalweightontherearaxleismeasuredwith
onlytherearwheelsonthescales;theweightonthefront
axleismeasuredwithonlythefrontwheelsonthescales.
NOTE:Theloadcapacityofthetiresmaybelowerthan
theloadcapacityofthefrontaxle;ifthisisthecase,the
lowervalueofthetwomustbeused.
LEEN11T0195AA_23
Frontaxlemaximumpermissibleloadingwithballastand
loaderintheraisedpositionwithnoloadinthebucket:
Staticloadrating=22500daN(50584.53lbf).
Dynamicloadrating=9000daN(20233.81lbf)[speed
40km/h(24.8mph)].
Rearaxlemaximumpermissibleloadingwithballastand
loaderintheraisedpositionwithnoloadinthebucket:
Staticloadrating=22500daN(50584.53lbf).
Dynamicloadrating=9000daN[speed40km/h
(24.8mph)].
LEEN11T0196AA_14
