6-WORKINGOPERATIONS
Machineweighing
Whenaddingballasttothemachine,donotexceedthe
grossweightshownontheidenticationplates.
NOTE:Thetotalweightontherearaxleismeasuredwith
onlytherearwheelsonthescales;theweightonthefront
axleismeasuredwithonlythefrontwheelsonthescales.
LEEN11T0193AA_11
2WS
NOTE:Theloadcapacityofthetiresmaybelowerthan
theloadcapacityofthefrontaxle;ifthisisthecase,the
lowervalueofthetwomustbeused.
Fourwheeldrive(4WD)frontaxlemaximumpermissible
loadinginclusiveofballastandloaderintheraisedposi-
tionwithnoloadinthebucket:
Staticloadrating=22500daN(50584.53lbf).
Dynamicloadrating=9000daN(20233.81lbf)[speed
40km/h(24.8mph)].
Rearaxlemaximumpermissibleloadingwithballastand
backhoeintheraisedpositionwithnoloadinthebucket:
Staticloadrating=18750daN(42153.78lbf).
Dynamicloadrating=7500daN[speed40km/h
(24.8mph)].
