2-SAFETYINFORMATION

Handsignals

Whenoperatingthemachine,neverattempttocarryouttaskscallingfornecontrolortoworkinareaswherevisibility

ispoororduringreversetravel,withoutseekingtheassistanceofaagman.Makeperfectlysurethatyouandthe

agmanunderstandthesignalstobeused.Theagmanmustalwayskeepoutofthemachine’sworkingarea.

Theoperatormustalwayskeepvisualcontactwiththeagman,stopthemachineimmediatelyifthecontactislost.

Starttheengine

MOLI12LBB0069AA1

Stoptheengine

MOLI12LBB0070AA2

Cometome

MOLI12LBB0071AA3

2-19
