7-MAINTENANCE

WARNING

Roll-overhazard!

Afteranaccident,re,tipover,orrollover,

aqualiedtechnicianMUSTreplacethe

Roll-OverProtectiveStructure(ROPS)before

returningthemachinetotheeldorjobsite

operation.

Failuretocomplycouldresultindeathorseri-

ousinjury.

W0134A

WARNING

Misusehazard!

Yourmachineisequippedwithanoperator

protectivestructure.DONOTweld,drillholes,

attempttostraighten,orrepairtheprotective

structure.Modicationinanywaycanreduce

thestructuralintegrityofthestructure.

Failuretocomplycouldresultindeathorseri-

ousinjury.

W0001B

NOTE:Foryoursafety,themachinecabhasbeende-

signedtopreventamepropagationandtolimitcombus-

tionsincaseofre.ThemachinecabcompliestoEuro-

peanstandardISO3795.

TheLoaderhasaROPS/FOPSsignshowingthecer-

ticationoftheROPS/FOPS,grossweight,approval,

regulation,andmodelnumberofthemachine.

LEEN11T0376AA1

7-40
