7-MAINTENANCE

10.Fullyinsertthelter(2).

11.Pushandholdtheretainingbracket(1)againstthe

lter(2).

RAIL15TLB0552BA6

12.Securethelterpositionwiththelockingclip(1).

RAIL15TLB0607BA7

13.Slidethegridcoveroverthelterhousing.Makesure

thattheslidingcoverrails(1)engagewiththelter

housingrails(2)onbothsides.

14.Makesurethatthegridcoverisevenlyandfullyinthe

downposition.

RAIL15TLB0551BA8

7-46
