7-MAINTENANCE

Frontaxle-Greasing

Pivot-2WS

1.Numberofgreasettings(1):1

LEEN11T0412AA7

Bearingsupports-4WS

2.Numberofgreasettings(2):2

LEEN11T0385AA8

Greasespecications

UseCASEAKCELAMOLYGREASE(MAT3550)or

agreasewhichmeetsthefollowingstandard:

•

NLGI2

NOTE:TUTELAMULTI-PURPOSEEPGREASE251H,GR-9

canalsobeused.

7-55
