7-MAINTENANCE
Rearaxle-Oilchange
1.Movethemachinetoalevelandrmground.
2.Lowertheloaderattachmenttotheground.
3.Placethebackhoeattachmentintheroadtravelposi-
tion.
4.Placethedirection-of-travelleverandgearshiftleverin
neutralposition.
5.Immobilizethemachinewiththeparkingbrake.
6.Stoptheengineandremovethestarterswitchkey.
LEEN11T0362AA6
Rearaxledifferentialoilchange
2WS
1.Placeacontainerwithsuitablecapacityundertheplug
(1).
2.Unscrewandremovetheplugs(1)and(2).
3.Waitfortheoiltocomeoutoftheaxlethroughthehole
oftheplug(1).
4.Afterdrainiscomplete,screwintheplug(1).
5.Fillwithcleanoilthroughtheholeoftheplug(2)until
thelevelreachesthehole.
6.Retightentheplug(2).
LEEN11T0386AA7
Oilspecicationandcapacities
UseCASEAKCELATRANSAXLEFLUID80W-140(
MAT3510)oranoilmeetingthebelowstandard:
•
SAE80W-140
NOTE:TUTELATRANSAXLEFLUIDSAE80W-140canalso
beused.
Capacities:
•
Rearaxledifferential(580T-580ST):15.5L
(4.09USgal)
•
Rearaxledifferential(590ST-695ST):17L
(4.49USgal)
