10-ACCESSORIES

4.Rotatethebucketoutandlowertotheground.

5.Rotatethequickcoupleroutofthebucket.

6.Pickupthenextbucketandraisetheboom.

RCPH10TLB397AAF3

7.Suspendthebucketofftheground,retractthebucket

cylinderuntilthebucketstartstorotateout.

8.Installthebucketpin,thesteelwasher,andthesnap

ring.

RCPH10TLB398AAF4
