3-CONTROLSANDINSTRUMENTS

Seatbelt

Toattachtheseatbelt(4),insertthebuckleintothesocket

(5).

Toreleasethebelt,pressthebuttononthesocket(5).

LEEN11T0460AA5

Seatbackangleadjustment

Toadjusttheseatbackangle,holdthelever(6)rearward,

movetheseatbacktoobtainthedesiredpositionandthen

releasethelever.

Swing

Releasetheseatusinglever(7)andswingitround.Re-

leasetheleverandmakesuretheseatislockedcorrectly

inplace.

LEEN11T0461AA6

3-7
