3-CONTROLSANDINSTRUMENTS

Adjustablesteeringcolumn(Optional)

WARNING

Drivinghazard!

Donotadjustthesteeringcolumnwhiledriving.

Beforeadjustingthesteeringcolumn:

-stopthemachine,

-putthegearshiftleverinneutral,and

-applytheparkingbrake.

Failuretocomplycouldresultindeathorseriousinjury.

W1032A

Theangleofthesteeringcolumncanbevariedthrough

anapproximaterangeof10°to20°.

Adjustmentisbyreleaseofthefootpedal(1)atthebase

ofthecolumn.Applyalightpressuretothispedaland

positionthesteeringcolumntosuityourneeds.

Withthecolumninthedesiredpositionreleasethefoot

pedalwhichwilllockthecolumninposition.

LEEN11T0040AA2

3-11
