OPERATING INSTRUCTIONS
109
RIGHT PAGE
Bur 6-34090EUR
Two Spool Valve - One Control Lever
BC01E131
NOTE: This page shows the basic
loader control lever positions. The
Detent Switch for the loader functions
is in the OFF position.
See Loader Function Switches in this
manual for RETURN-TO-DIG,
BUCKET HEIGHT CONTROL and
RETURN-TO-TRAVEL/FLOAT
switches.
B1119A88J
HOLD: The loader arms and bucket will not move when the control lever is in
HOLD. When released, the control lever will return to HOLD automatically.
1
2
3
4
5
1. DUMP 2. ROLLBACK 3. LOWER 4. RAISE
1
2
3
4
5
