OPERATING INSTRUCTIONS
110
LEFT PAGE
Bur 6-34090EUR
Three Spool Valve - Three Control Levers
BC01E132
NOTE: This page shows the basic
loader control lever positions. The
Detent Switch for the loader functions
is in the OFF position.
See Loader Function Switches in this
manual for RETURN-TO-DIG,
BUCKET HEIGHT CONTROL and
RETURN-TO-TRAVEL/FLOAT
switches.
BS00C008
HOLD: The loader arms, bucket, and clam will not move when the control
levers are in HOLD. When released, the control levers will return to HOLD
automatically.
7
7
7
5
6
4
3
1
2
1. CLAM OPEN (IF EQUIPPED 3. DUMP 5. LOWER
2. CLAM CLOSED (IF EQUIPPED) 4. ROLLBACK 6. RAISE
1
2
4
5
3
6
7
To Next Page
