LUBRICATION/FILTERS/FLUIDS

169

RIGHT PAGE

Bur 6-34090EUR

Hydraulic/Brake Oil Change

64L95

1. FILLER CAP 4. DRAIN VALVE

2. SUCTION SCREEN 5. ACCESS COVER

3. RESERVOIR FILTER 6. SEAL
