Case 921C User Manual

INSTRUMENTS/CONTROLS
71
RIGHT PAGE
Bur 6-34090EUR
Two Spool - Two Levers
BC01E133/BS00B354
4. BUCKET CONTROL
A. DUMP
B. ROLLBACK
C. HOLD: The bucket will not move when the control lever is in the HOLD
position. When released, the control lever will automatically return to the
HOLD position.
5. LIFT ARM CONTROL
D. FLOAT (Detent): This is a detent position. When in the FLOAT (Detent)
position, the loader bucket can follow the level of the ground without
movement of the control lever.
E. LOWER
F. HOLD: The loader arms will not move when the control lever is in the
HOLD position. When released, the control lever will automatically return to
the HOLD position. You must manually move the control lever from the
FLOAT position to the HOLD position.
G. RAI S E
B
C
G
F
E
D
A
4
5
4
5
