INSTRUMENTS/CONTROLS

LEFT PAGE

Bur 6-34090EUR

Two Spool - Two Levers

(Continued)

BC01E133

6. Kickdown Button (Downshift Transmission)

7. FNR Switch

A. Forward (Transmission)

B. Neutral (Transmission)

C. Reverse (Transmission)
