CHK Power Quality Pty Ltd, User Manual – Miro Power Quality Logger and Analyser, 15 August 2016
Website: www.chkpowerquality.com.au; Enquiries: sales@chkpowerquality.com.au; Page 11
Address: Unit 1, 3 Tollis Place, Seven Hills, NSW 2147, Sydney, Australia; ABN: 53 169 840 831; Telephone: +61 2 8283 6945;
Fax: +61 2 8212 8105; Website: www.chkpowerquality.com.au
Figure 1.1.2.4 - Miro PQ45
1.2 Kits and accessories
1.2.1 PQ25/35/45 kits
Standard kit for either the PQ25/35/45 includes:
1 x power quality instrument
4 x high sensitivity flexible current sensors (30-3600)A, 600mm diameter
2 x temperature sensors (free end + magnetic mount)
1 x set of voltage leads with banana ends with small clamps
1 x regulated DC adaptor;
1 x single phase power cable
1 x carry bag
1 x CD (Latest version of CITRUS application software and user manual)
Note that each unit is GPS enabled.
Each kit comprises of accessories with the colour code below.
1.2.2 Instruments
PQ25 Power quality logger and analyser
PQ35 Power quality logger and analyser
PQ45 Power quality logger and analyser
1.2.3 Accessories
