CHK Power Quality Pty Ltd, User Manual Miro Power Quality Logger and Analyser, 15 August 2016
Website: www.chkpowerquality.com.au; Enquiries: sales@chkpowerquality.com.au; Page 12
Address: Unit 1, 3 Tollis Place, Seven Hills, NSW 2147, Sydney, Australia; ABN: 53 169 840 831; Telephone: +61 2 8283 6945;
Fax: +61 2 8212 8105; Website: www.chkpowerquality.com.au
1.2.3.1 Current sensors and converters
Part number
Description
Instrument
Quantity
required
1ACF3000-9
CT 3000A Flexible (100-3600A)
PQ25/35
/4
1ACK1
Converter current 1A:200mA PQ
PQ25/35
1
1ACK5
Converter current 5A:200mA PQ
PQ25/35
1
1ACR100
CT 100A 52mm Iron (10-120A)
PQ25/35
/4
1ACR1000
CT 1000A Clip-on (100-1200A)
PQ25/35
/4
1ACR100S
CT 100A 15mm Iron (10-120A)
PQ25/35
/4
1ACR500
CT 500A 52mm Iron (50-600A)
PQ25/35
/4
1ACF3000-6
CT 3000A, Flexible 600mm (100-3600A) [Blue]
PQ25/35
/4
1ACF3000-6-H
CT 3000A, Flexible 600mm (30-3600A) [Blue]
PQ25/35
/4
1ACF3000-9
CT 3000A, Flexible 900mm (100-3600A) [Blue]
PQ25/35
/4
1AFF3000-6
CT 3000A, Flexible 600mm, 100-3600A Green]
PQ25/35
/4
1AFF500-0.55
Flexible current sensor 500A [Red]
PQ25/35
/4
1AC10
CT 10A 15mm Iron
PQ45
/4
1AC100S
CT 100A 15mm Iron (10-120A)
PQ45
/4
1ASC500
CT 500A 52mm Iron (50-600A) CAT IV 600V
PQ45
/4
1AF3000-6
CT 3000A, Flexible 600mm (100-3600A) [Blue]
PQ45
/4
1AF3000-6-H
CT 3000A, Flexible 600mm (30-3600A) [Blue]
PQ45
/4
1AF3000-9
CT 3000A, Flexible 900mm (100-3600A) [Blue]
PQ45
/4
SAF3000-B
CT 3000A, Flexible 600mm (100-3600A)
[Green]
PQ45
/4
1.2.3.2 Voltage leads and attachments
Part number
Description
Instrument
Quantity
required
1APC4
Single phase power lead
PQ25/35
1
1APC5
Single phase power lead
PQ45
1
1AVL3
3-Wire (Delta) voltage cable
PQ35
1
1AVL4C2
4 wire voltage lead with large clamps
PQ25/35
1
1AVL4
4 wire voltage lead (3P+N)
PQ25/35
1
1AAC1NCL/BK
Black voltage clamp lead
VL
1
1AAC1NCL/BU
Blue voltage clamp lead
VL
1
1AAC1NCL/RD
Red voltage clamp lead
VL
1
1AAC1NCL/WH
White voltage clamp lead
VL
1
1AVL6
PQ35
1
1AAC6BC-1
Banana plug fused attachment
PQ35
1
1AAC6BC-2
Banana plug fused attachment
PQ35
1
1AVL5-B
5 wire - banana /small clamps voltage lead
PQ45
1
1AVL5-C
5 wire - large clamps voltage lead
PQ45
1
1AVL8-B
8 wire - banana /small clamps voltage lead
PQ45
1
1AVL8-C
8 wire - large clamps voltage lead
PQ45
1
10169
2A HRC fuse for voltage cable
VL
4
1AAC4BC
Banana plug fused attachment
VL
1
1AAC4TE
Tinned end fused attachment
VL
1
