9.2.2.7 Clamp on CT probes 15mm - 10A
Clamp on CT probe 15mm - 10A
Instrument: PQ45.
Part number: 1AC10.
Accuracy: ±1%.
Cable diameter: 15mm.
Rated current: 10Arms.
Frequency range: 45Hz-5kHz.
Safety rating: 600V CAT III.
Weight: 113g (excluding lead).
Cable length: 1.95m.
Figure 9.2.2.7.1
9.2.2.8 Clamp on CT probes 15mm - 100A
Clamp on CT probe 15mm - 100A
Instrument: PQ45.
Part number: 1AC100S.
Accuracy: ±1%.
Cable diameter: 15mm.
Rated current: 100Arms.
Frequency range: 45Hz-5kHz.
Safety rating: 600V CAT III.
Weight: 113g (excluding lead).
Cable length: 1.95m.
Figure 9.2.2.8.1
