Figure 5.9.3.7.3
5.9.4 Measurements
There are five measurement groups as shown in figure 5.9.4.1 and include RMS and
Frequency, Power and Unbalance, Harmonics, Flicker and Temperature.
Figure 5.9.4.1
5.9.4.1 RMS and frequency
Clicking on ’RMS and Frequency’ in the ‘Measurements’ menu generates a sub menu listing
’TRMS’, ‘DC’, ‘AC’, ‘Crest Factor’, ‘Fundamental Magnitude’, ‘Fundamental Phase’,
‘Frequency’, ‘Underdeviation’ and ‘Overdevaition’ measures as shown in figure 5.9.4.1.1.
