9.2.1.5 Clamp on CT probes 52mm - 500A
Clamp on CT probe 52mm - 500A
Instrument: PQ25 and PQ35.
Part number: 1ACR500.
Accuracy: ±0.5%.
Cable diameter: 52mm.
Rated current: 500Arms.
Frequency range: 5Hz-5kHz.
Weight: 750g.
Cable length: 1.95m.
Protection level: CAT IV 600V.
Figure 9.2.1.5.1
9.2.1.6 Clamp on CT probes 52mm - 1000A
Clamp on CT probe 52mm - 1000A
Instrument: PQ25 and PQ35.
Part number: 1ACR1000.
Accuracy: ±0.5%.
Cable diameter: 52mm.
Rated current: 1000Arms.
Frequency range: 5Hz-5kHz.
Weight: 750g.
Cable length: 1.95m.
Protection level: CAT IV 600V.
Figure 9.2.1.6.1
