CHK Power Quality MIRO PQ25 User Manual

CHK Power Quality Pty Ltd, User Manual – Miro Power Quality Logger and Analyser, 15 August 2016
Website: www.chkpowerquality.com.au; Enquiries: sales@chkpowerquality.com.au; Page 71
Address: Unit 1, 3 Tollis Place, Seven Hills, NSW 2147, Sydney, Australia; ABN: 53 169 840 831; Telephone: +61 2 8283 6945;
Fax: +61 2 8212 8105; Website: www.chkpowerquality.com.au
Figure 5.9.1.3.1
Figure 5.9.1.3.2
Step 2: Hover and click on ’Remove File’. A window appears listing all open files as shown
in figure 5.9.1.3.3.
Figure 5.9.1.3.3
Step 3: Select the file you wish to remove and click on the ’OK’ button.
5.9.1.4 Exit
The user is able to close the file viewer by two methods.
Method 1
Step 1: Click the ’File’ menu shown in figure 5.9.1.4.1. A drop down box appears as shown
in figure 5.9.1.4.2.
Figure 5.9.1.4.1
Figure 5.9.1.4.2
Step 2: Hover and click on ’Exit’.
