CHK Power Quality MIRO PQ25 User Manual

CHK Power Quality Pty Ltd, User Manual – Miro Power Quality Logger and Analyser, 15 August 2016
Website: www.chkpowerquality.com.au; Enquiries: sales@chkpowerquality.com.au; Page 213
Address: Unit 1, 3 Tollis Place, Seven Hills, NSW 2147, Sydney, Australia; ABN: 53 169 840 831; Telephone: +61 2 8283 6945;
Fax: +61 2 8212 8105; Website: www.chkpowerquality.com.au
11.2.5 Three phase 2-Watt 3 wire Delta source with Delta load (VL6 cable)
a. Connection diagram using 6-Wire Voltage Cable (VL6).
b. NC (not connected).
Circuit summary table
Voltage lead connection
Source
Delta
Phase A
Red
Load
Delta
Neutral A
Red/Black
Connection type
Delta
Phase B
White
Nominal RMS
Phase-Phase
Neutral B
White/Black
Phase C
Blue
Neutral C
Blue/Black
Voltage
Current
A
B
C
N
Source
Load
Phase A
Phase B
Phase C
Red
Red/Black
White/Black
White
Blue
Blue/Black
VL6
Floating or Grounded Delta
