5.3.14.8 Combining charts
The user is able to combine the ‘Volts and Amps’ view into a single chart by deselecting the
‘Split Volts/Amps’ check box and then again selecting the desired event.
Figure 5.3.14.81.1 shows the combined charts of that of figure 5.3.14.7.3.
Figure 5.3.14.8.1
