CHK Power Quality MIRO PQ25 User Manual

CHK Power Quality Pty Ltd, User Manual – Miro Power Quality Logger and Analyser, 15 August 2016
Website: www.chkpowerquality.com.au; Enquiries: sales@chkpowerquality.com.au; Page 216
Address: Unit 1, 3 Tollis Place, Seven Hills, NSW 2147, Sydney, Australia; ABN: 53 169 840 831; Telephone: +61 2 8283 6945;
Fax: +61 2 8212 8105; Website: www.chkpowerquality.com.au
11.3.2 Split phase with 2 single phase loads (VL5 cable)
a. Connection diagram using 5-Wire Voltage Cable (VL5).
b. NC (not connected).
Circuit summary table
Voltage lead connection
Source
Split phase
Phase A
Red
Load
2 Single phase
Phase B
White
Connection type
Star/Wye
Phase C
Blue
Nominal RMS
Phase-Neutral
Neutral
Black
Gnd
Green
Voltage
Current
A
B
C
N
Source
Load
Phase A
Phase B
Optional
Neutral
Gnd
VL5
Red
White
Blue
Black
