11.3 Split phase
11.3.1 Split phase 3 wire with 2 single phase loads (VL4 cable)
a. Connection diagram using 4-Wire Voltage Cable (VL4).
b. NC (not connected).
Circuit summary table
Voltage lead connection
Source
Split phase
Phase A
Red
Load
2 Single phase
Phase B
White
Connection type
Star/Wye
Phase C
Blue
Nominal RMS
Phase-Neutral
Neutral
Black
NC
Voltage
Current
A
B
C
N
Source
Load
Phase A
Phase B
Optional
Neutral
VL4
Red
White
Blue
Black
