Figure 5.9.2.7.7
Hiding the text annotation
Hovering the mouse pointer in the text box and then holding down the left hand side button
on the mouse drag the box away from the graph area and release the mouse button.
5.9.2.8 Add arrow annotation
The user is able to insert an arrow onto the graph.
Step 1: Click the ’View’ menu shown in figure 5.9.2.8.1. A drop down box appears as shown
in figure 5.9.2.8.2.
