Chronos 1.4 - Power Status Indicator; Jog Wheel; Sd Card Slot

Page | 39
POWER STATUS INDICATOR
• Indicates the presence of AC power and the charge status of the battery.
LED
Indication
Un-Lit
No AC Power Connected
Solid Yellow
Charging, less than 80%
charged
Alternating
Green/Yellow
Charging, more than 80%
charged
Green
Battery fully charged
JOG WHEEL
• Used for playback control, adjusting shutter speed, and UI navigation and
input.
• During playback, moves playback 1 frame per detent (rotation click).
• Press and hold the dial clicked in to move fast (40 frames per detent)
• On the Main screen, rotation adjusts shutter speed.
• During UI navigation, rotation cycles through the widgets on the user
interface, and a click will activate the highlighted widget.
SD CARD SLOT
• Videos can be saved to the card in this slot.
• For fastest saving, a Class 10 or faster SD card is recommended, however,
any properly formatted SD card will work. (FAT32, EXT2 and EXT3 file
systems are supported)
