Chronos 1.4 - Chronos 2.1-Hd

Page | 54
CHRONOS 2.1-HD
Camera
Imaging
1920 x 1080 1000FPS
Memory
8GB, 16GB, 32GB
Record Time
2.7 Sec (8GB), 5.5 Sec (16GB), 11 Sec (32GB)
Lens Mount
CS/C mount, Nikon F, Canon EF with adapter
Back-Focus
Field adjustable
IR Filter
650nm, removable, 24mm x 16mm x 1.1mm
Display
5” 800 x 480 Capacitive touchscreen, 1000nit
daylight visible
Enclosure
Anodized CNC machined aluminum
Cooling
Active cooling, variable-speed fan
Dimensions
155mm x 96mm x 67.3mm
(6.11” x 3.78” x 2.65”) without lens
Weight
1.06Kg (2.34lbs) without lens
Video Formats
H.264
Industry standard mp4 files at bitrates up to
60Mbps
CinemaDNG Raw
Standard Adobe CinemaDNG raw files
Image Sensor
Resolution
1920 x 1080 @ 1000FPS
Speed
2.1Gpx/s
Dimensions
19.2mm x 10.8mm (4/3” format)
Pixel Pitch
10um
Sensitivity (ISO)
Color: ISO 500 base
Mono: ISO 1000 base
Shutter
Electronic global shutter,
1/fps to 10us (1/100,000s)
Dynamic Range
10.3 stops (62.4 dB) (preliminary)
Bit Depth
12-bit
