Chronos 1.4 - Page 52

Page | 52
Bit Depth
12-bit
Battery
Type
EN-EL4a
Run Time
1.5 hours recording (typical)
Charge Time
2 hours (0-80%)
IO
Power Input
17-20V 40W
5.5/2.5mm barrel jack, positive tip
Network
Gigabit Ethernet
Trigger
Two Trigger inputs/frame probe outputs
(BNC & Aux)
Adjustable Input Threshold 0 to 6.6Volts
Electrically isolated trigger input (Aux
Connector)
Audio
Microphone/Line input, headphone output
Video
HDMI output, video only
HDMI output, video+menus
USB
2x USB hosts ports
(one on mini-B via USB OTG cable)
SATA
eSATA 3G
Analog Input*
1MSa/s 12-bit, 200Khz bandwidth, +/- 1V full
scale
Trigger Modes
Normal Triggered
Camera records until a defined delay after
trigger
Trigger Start
Camera starts recording after a defined delay
after a trigger
Trigger Source
Electrical
0-6.6V threshold, optional button debounce and
pullup
Audio*
Trigger on loud sounds
Acceleration*
Trigger on camera motion, tilt or shock
Image*
Trigger on image changes
