RECORD SETTINGS [CONTINUED]
Increases the brightness in the scene by automatically modifying White Balance
and Color Matrix settings. As starting points, this function uses CIECAM16/D55
and a color temperature of 3200K (Tungsten). A setting of None will not modify
existing settings.
Select a pre-set from common picture sizes and frame rates.
The frame rate will automatically be set to the maximum for the selected pre-set.
Shows the size and position of the recorded area in relation to the sensor’s full
resolution. The outer box represents the sensor’s maximum resolution, and the
inner box represents the area on the image sensor that will be recorded, given
the currently selected resolution and offset.
Shows the maximum frame rate and minimum period for the current resolution
setting.
Opens a screen to configure the amount of record time before and after a
triggered event. Trigger delay only applies to external triggers through the BNC
connector, or the Auxiliary I/O connector on the side of the camera, but not the
red shutter button on top of the camera.
Opens a screen to switch between Normal, Segmented, Gated Burst and Live
Slow-Motion modes.
Applies changes and closes window.
Discards changes and closes window.
