DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Identifies a specific line to configure, and enter in-line
configuration mode.
line [console | vty] line-number
Example:
Switch(config)# line console 0
Step 2
• console—Specifies the console terminal line. The console
port is DCE.
• vty—Specifies a virtual terminal for remote console access.
The line-number is the first line number in a contiguous group
that you want to configure when the line type is specified. The
range is from 0 to 16.
Restricts incoming and outgoing connections between a particular
virtual terminal line (into a device) and the addresses in an access
list.
access-class access-list-number {in | out}
Example:
Switch(config-line)# access-class 10 in
Step 3
Returns to privileged EXEC mode.end
Example:
Switch(config-line)# end
Step 4
Displays the access list configuration.show running-config
Example:
Switch# show running-config
Step 5
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config startup-config
Step 6
Applying an IPv4 ACL to an Interface
This section describes how to apply IPv4 ACLs to network interfaces.
Catalyst 2960-XR Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX1
130 OL-29434-01
Configuring IPv4 ACLs
Applying an IPv4 ACL to an Interface

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
