Cisco Catalyst 2960-XR User Manual

PurposeCommand or Action
• use-svi—Uses the switch virtual interface (SVI) IP address as
source of ARP probes.
Configures the network access server to recognize and use
vendor-specific attributes.
radius-server vsa send authentication
Example:
Switch(config)# radius-server vsa send
Step 10
The downloadable ACL must be
operational.
Note
authentication
Returns to privileged EXEC mode.end
Example:
Switch(config)# end
Step 11
Configuring VLAN ID-based MAC Authentication
Beginning in privileged EXEC mode, follow these steps:
SUMMARY STEPS
1.
configure terminal
2.
mab request format attribute 32 vlan access-vlan
3.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Enables VLAN ID-based MAC authentication.mab request format attribute 32 vlan access-vlan
Example:
Switch(config)# mab request format attribute 32 vlan
Step 2
access-vlan
Catalyst 2960-XR Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29434-01 293
Configuring IEEE 802.1x Port-Based Authentication
Configuring VLAN ID-based MAC Authentication

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
