This example shows how to configure an ARP ACL called host2 on Switch A, to permit ARP packets from
Host 2 (IP address 1.1.1.1 and MAC address 0001.0001.0001), to apply the ACL to VLAN 1, and to configure
port 1 on Switch A as untrusted:
Switch(config)#arp access-list host2
Switch(config-arp-acl)#permit ip host 1.1.1.1 mac host 1.1.1
Switch(config-arp-acl)# exit
Switch(config)# ip arp inspection filter host2 vlan 1
Switch(config)# interface gigabitethernet1/0/1
Switch(config-if)# no ip arp inspection trust
Configuring Dynamic ARP Inspection in DHCP Environments
Before You Begin
This procedure shows how to configure dynamic ARP inspection when two switches support this feature.
Host 1 is connected to Switch A, and Host 2 is connected to Switch B. Both switches are running dynamic
ARP inspection on VLAN 1 where the hosts are located. A DHCP server is connected to Switch A. Both hosts
acquire their IP addresses from the same DHCP server. Therefore, Switch A has the bindings for Host 1 and
Host 2, and Switch B has the binding for Host 2.
Dynamic ARP inspection depends on the entries in the DHCP snooping binding database to verify
IP-to-MAC address bindings in incoming ARP requests and ARP responses. Make sure to enable DHCP
snooping to permit ARP packets that have dynamically assigned IP addresses.
Note
Beginning in privileged EXEC mode, follow these steps to configure dynamic ARP inspection. You must
perform this procedure on both switches. This procedure is required.
SUMMARY STEPS
1.
show cdp neighbors
2.
configure terminal
3.
ip arp inspection vlan vlan-range
4.
Interfaceinterface-id
5.
ip arp inspection trust
6.
end
7.
show ip arp inspection interfacesshow ip arp inspection vlan vlan-range
8.
show ip dhcp snooping binding
9.
show ip arp inspection statistics vlan vlan-range
10.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Verify the connection between the switches.show cdp neighbors
Step 1
Catalyst 2960-XR Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29434-01 205
Configuring Dynamic ARP Inspection
Configuring Dynamic ARP Inspection in DHCP Environments

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
