PurposeCommand or Action
(Optional) Configures the parameters for inaccessible authentication bypass:dot1x critical {eapol | recovery delay
milliseconds}
Step 5
eapol—Specifies that the switch sends an EAPOL-Success message when the
switch successfully authenticates the critical port.
Example:
Switch(config)# dot1x critical eapol
recovery delay milliseconds—Sets the recovery delay period during which
the switch waits to re-initialize a critical port when a RADIUS server that was
recovery delay 2000
unavailable becomes available. The range is from 1 to 10000 milliseconds.
The default is 1000 milliseconds (a port can be re-initialized every second).
Specify the port to be configured, and enter interface configuration mode.
interface interface-id
Example:
Switch(config)# interface
Step 6
gigabitethernet 1/0/1
Moves hosts on the port if the RADIUS server is unreachable:authentication event server dead action
{authorize | reinitialize} vlan vlan-id]
Step 7
• authorize–Moves any new hosts trying to authenticate to the
user-specified critical VLAN.
Example:
Switch(config-if)# authentication
• reinitialize–Moves all authorized hosts on the port to the user-specified
critical VLAN.
event server dead action
reinitialize vlan 5
Enables the inaccessible authentication bypass feature, and use these keywords
to configure the feature:
dot1x critical [recovery action
reinitialize | vlan vlan-id]
Step 8
Example:
Switch(config-if)# dot1x critical
• authorize—Authorizes the port.
• reinitialize—Reinitializes all authorized clients.
recovery action reinitialize
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 9
Example of Configuring Inaccessible Authentication Bypass
This example shows how to configure the inaccessible authentication bypass feature:
Switch(config)# radius-server dead-criteria time 30 tries 20
Switch(config)# radius-server deadtime 60
Switch(config)# radius-server host 1.1.1.2 acct-port 1550 auth-port 1560 test username user1
idle-time 30 key abc1234
Switch(config)# dot1x critical eapol
Switch(config)# dot1x critical recovery delay 2000
Catalyst 2960-XR Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX1
276 OL-29434-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring the Inaccessible Authentication Bypass Feature

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
