PurposeCommand or Action
encapsulation dot1q
Configures the interface as a VLAN trunk port.switchport mode trunk
Example:
Switch(config-if)# switchport mode trunk
Step 9
Configures the interface as a port access entity (PAE)
supplicant.
dot1x pae supplicant
Example:
Switch(config-if)# dot1x pae supplicant
Step 10
Attaches the 802.1x credentials profile to the interface.
dot1x credentials profile-name
Example:
Switch(config-if)# dot1x credentials test
Step 11
Returns to privileged EXEC mode.end
Example:
Switch(config-if)# end
Step 12
Verifies your configuration.
show running-config interface interface-id
Example:
Switch# show running-config interface
Step 13
gigabitethernet1/0/1
(Optional) Saves your entries in the configuration file.copy running-config startup-config
Example:
Switch# copy running-config startup-config
Step 14
You can also use an Auto Smartports user-defined macro
instead of the switch VSA to configure the authenticator
Configuring NEAT with Auto Smartports Macros
Step 15
switch. For more information, see the Auto Smartports
Configuration Guide for this release.
Catalyst 2960-XR Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX1
288 OL-29434-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring a Supplicant Switch with NEAT

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
