SUMMARY STEPS
1.
configure terminal
2.
interface interface-id
3.
switchport mode access
4.
authentication control-direction {both | in}
5.
authentication fallback name
6.
authentication host-mode [multi-auth | multi-domain | multi-host | single-host]
7.
authentication open
8.
authentication order [ dot1x | mab ] | {webauth}
9.
authentication periodic
10.
authentication port-control {auto | force-authorized | force-un authorized}
11.
end
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Specifies the port to be configured, and enter interface
configuration mode.
interface interface-id
Example:
Switch(config)# interface gigabitethernet 1/0/1
Step 2
Sets the port to access mode only if you configured
the RADIUS server.
switchport mode access
Example:
Switch(config-if)# switchport mode access
Step 3
(Optional) Configures the port control as
unidirectional or bidirectional.
authentication control-direction {both | in}
Example:
Switch(config-if)# authentication control-direction
Step 4
both
(Optional) Configures a port to use web authentication
as a fallback method for clients that do not support
802.1x authentication.
authentication fallback name
Example:
Switch(config-if)# authentication fallback profile1
Step 5
Catalyst 2960-XR Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX1
296 OL-29434-01
Configuring IEEE 802.1x Port-Based Authentication
Configuring Open1x

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
