Cisco Catalyst 2960-XR User Manual

SUMMARY STEPS
1.
enable
2.
configure terminal
3.
line vty 0 15
4.
password password
5.
end
DETAILED STEPS
PurposeCommand or Action
If a password is required for access to privileged EXEC mode,
you will be prompted for it.
Note
Enters privileged EXEC mode.
enable
Example:
Switch> enable
Step 1
Enters global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 2
Configures the number of Telnet sessions (lines), and enters line
configuration mode.
line vty 0 15
Example:
Switch(config)# line vty 0 15
Step 3
There are 16 possible sessions on a command-capable switch. The 0
and 15 mean that you are configuring all 16 possible Telnet sessions.
Sets a Telnet password for the line or lines.
password password
Step 4
Example:
Switch(config-line)# password
For password, specify a string from 1 to 25 alphanumeric characters.
The string cannot start with a number, is case sensitive, and allows spaces
but ignores leading spaces. By default, no password is defined.
abcxyz543
Returns to privileged EXEC mode.end
Example:
Switch(config-line)# end
Step 5
Related Topics
Preventing Unauthorized Access, on page 19
Terminal Line Telnet Configuration, on page 23
Catalyst 2960-XR Switch Security Configuration Guide, Cisco IOS Release 15.0(2)EX1
OL-29434-01 29
Controlling Switch Access with Passwords and Privilege Levels
Setting a Telnet Password for a Terminal Line

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
