Chapter 2 Introduction to the Cisco SCE8000 GBE Platform
Checking the Shipping Container Contents
Cisco SCE8000 GBE Component List
Table 2-11 lists the Cisco SCE8000 GBE components.
Note Cisco does not ship the entire Cisco SCE8000 GBE documentation set automatically with each system.
You must specifically order the documentation as part of the sales order. If you ordered documentation
and did not receive it, we will ship the documents to you within 24 hours. To order documents, contact
a customer service representative.
Table 2-11 Cisco SCE8000 GBE Component List
Component Description
Cisco SCE8000 GBE platform Cisco SCE8000 GBE chassis configured with the following
components:
Cisco SCE8000-SCM-E Cisco SCE8000 GBE Service Control Module
Cisco SCE8000-SIP Cisco SCE8000 GBE SPA Interface Processor
1 or 2 8-port GBE SPA modules with
optionally 1 or 2 1-port 10GBE SPA
modules for cascade
SPA modules.
2 to 16 Optics SFP optic modules See the following lists of supported SFP models:
• SFP Module Connections, page 2-6
2 Cisco PWR-2700-AC/4 or
2 Cisco PWR-2700-DC/4
Cisco power supply units, AC or DC.
Hot swappable, redundant power supply.
SCE8000 GBE -FAN Redundant fans unit.
Accessories The following accessories might arrive in separate shipping
containers:
Management cables
• Gigabit Ethernet cable for connecting to the
Management ports
• RS-232 serial cables (DB-9 to RJ-45 and DB-25 to
RJ-45) for connecting to a local terminal
Power cables Two AC power supply cords, if ordered with AC-input power
supply units
Grounding kit 69-0815-01
• Grounding lug
• Two M4 hex-head screws with locking washers
Optical Bypass module kit
• Optical Bypass Module
• Control Cable (2 m)
• Control Cable (40 cm)
