Installing an Optical Bypass Module
There are two installation options for the external bypass modules:
• Chassis mount panel—This panel is mounted in slot #4 of the SCE8000 GBE chassis. It hosts four
optical bypass modules, which will serve the 16 traffic links supported by the Cisco SCE8000 GBE
platform.
• External mounting panel—This panel can be mounted in any 19" rack. It also hosts up to four optical
bypass modules, which will serve 16 traffic links.
Step 1 For external mounting, install the external mounting panel in the 19" rack. Screw the mounting panel to
the rack using four 3/4-inch screws, two on each side, through the holes in the mounting panel and into
the threaded holes in the rack posts.
For internal mounting, the SCE8000 GBE chassis will be shipped with the chassis mounting panel
already installed in slot #4.
Step 2 Remove the module filler plate covering the subslot in the mounting panel by loosening the two screws.
Step 3 Carefully insert the optical bypass module into the subslot (there are no guide rails) and tighten the
captive screws on either side of the module (Figure 4-15).
Figure 4-15 Optical Bypass Modules in External Mounting Panel
