Cisco SCE8000 GBE Installation and Configuration Guide
OL-19897-02
Chapter 2 Introduction to the Cisco SCE8000 GBE Platform
Introduction to SIPs and SPAs
Specifying the SIP Subslot Location for a SPA
Cisco SCE8000-SIP subslots begin their numbering with “0” and have a horizontal orientation.
Figure 2-3 shows the subslot numbering for the Cisco SCE8000-SIP.
The Cisco SCE8000-SIP supports four subslots for the installation of SPAs, as follows:
• SIP subslot 0—Top–left subslot
• SIP subslot 1—Top–right subslot
• SIP subslot 2—Bottom–left subslot
• SIP subslot 3—Bottom–right subslot
Figure 2-3 SPA Module Subslot Location
Shared Port Adapters
The following SPA modules are supported by the Cisco SCE8000-SIP:
• For traffic interfaces: 8-port Gigabit Ethernet SPA, SPA-8X1GE-V2
• For cascade interfaces: 1-Port 10-Gigabit Ethernet SPA, SPA-1X10GE-L-V2 (for cascaded systems
only)
The following list describes some of the general characteristics of a SPA:
• A SPA is a modular type of port adapter that inserts into a subslot of a compatible SIP carrier card
to provide network connectivity and increased interface port density. The Cisco SCE8000-SIP can
hold up to four SPAs.
• The supported SPA is a single-height SPAs, which inserts into one SIP subslot. (See Figure 2-4.)
Figure 2-4 Single-Height SPA Size
• Each 8-port Gigabit Ethernet SPA provides eight GBE ports, which interface with either subscriber
or network traffic. These interfaces can be individually configured using the Cisco command-line
interface (CLI).
8-port Gigabit Ethernet SPAs can be installed in subslots 0 and 1 only.
Sub-slot 0
Front of SCE8000-SIP
270900
Sub-slot 1
Sub-slot 2 Sub-slot 3
Single-height SPA
Front of the SCE8000-SIP
242234
Single-height SPA
Single-height SPA Single-height SPA
