Chapter 9 Removal and Replacement Procedures
Removing and Replacing the Optical Bypass Module
Installing a SPA in a SIP
To install a SPA in a SIP, refer to Figure 9-17 and do the following:
Step 1 At the SCE# prompt, type reload shutdown and press Enter to power down the Cisco SCE8000 GBE
platform before installing or removing any module.
Step 2 To insert the SPA in the SIP, locate the guide rails inside the SIP that hold the SPA in place. They are at
the top left and top right of the SPA slot and are recessed about an inch, as shown in Figure 9-17.
Step 3 Carefully slide the SPA all the way in the SIP until the SPA is firmly seated in the SPA interface
connector. When fully seated, the SPA might be slightly behind the SIP faceplate.
Step 4 After the SPA is properly seated, fasten the SPA in place with the captive installation screws.
Removing a SPA from a SIP
To remove a SPA from a SIP, refer to Figure 9-17 and do the following:
Step 1 At the SCE# prompt, type reload shutdown and press Enter to power down the Cisco SCE8000 GBE
platform before installing or removing any module.
Step 2 If attached, remove any cables from the SPA.
Step 3 To remove the SPA from the SIP, unfasten the captive installation screws on the SPA.
Step 4 Grasp the handles of the SPA and pull the SPA from the SIP.
Removing and Replacing the Optical Bypass Module
• Removing the Optical Bypass Module, page 9-27
• Installing the Optical Bypass Module, page 9-28
• Replacing the Optical Bypass Module without Disrupting Traffic on the Link, page 9-28
Removing the Optical Bypass Module
Step 1 Disconnect all cables.
Step 2 Loosen the two captive screws on the module.
Step 3 Pull the module out of the slot. Place your other hand under the module to support the weight of the
module. Do not touch the module circuitry.
Step 4 Place the module on antistatic foam, or immediately reinstall it in another slot.
Step 5 If the slot is to remain empty, install a module filler plate to keep dust out of the chassis and to maintain
proper airflow through the chassis.
