Cisco SCE8000 GBE - Optical Bypass Module Connectivity

6-5
Cisco SCE8000 GBE Installation and Configuration Guide
OL-19897-02
Chapter 6 Cabling the GBE Line Ports and Completing the Installation
The Optical Bypass Module
Optical Bypass Module Connectivity
Table 6-2 summarizes the connectivity for the optical bypass module for the SCE8000 GBE. Bypass
modules are required in the right-hand side only if there is an 8-port GBE SPA in subslot #1.
Table 6-2 Optical Bypass Module Connectivity
Connect this port on the external
bypass module. To this component Link number
External bypass module #1
A1 Subscriber side network element 0 0
B1 Network side network element 0 0
C1 SPA port 3/0/0 0
D1 SPA port 3/0/1 0
A2 Subscriber side network element 1 1
B2 Network side network element 1 1
C2 SPA port 3/0/2 1
D2 SPA port 3/0/3 1
CTRL (use the short leg of the ‘Y’
control cable labeled OPB CTRL1)
left-hand 'Optical Bypass' port on Cisco
SCE8000-SCM-E module (use the long leg of
the ‘Y’ control cable; it is labeled SCE8000
GBE -2L BYPASS)
External bypass module #2
A1 Subscriber side network element 2 2
B1 Network side network element 2 2
C1 SPA port 3/0/4 2
D1 SPA port 3/0/5 2
A2 Subscriber side network element 3 3
B2 Network side network element 3 3
C2 SPA port 3/0/6 3
D2 SPA port 3/0/7 3
CTRL (use the short leg of the ‘Y’
control cable labeled OPB CTRL2)
left-hand 'Optical Bypass' port on Cisco
SCE8000-SCM-E module (use the long leg of
the ‘Y’ control cable; it is labeled SCE8000
GBE -2L BYPASS)
External bypass module #3
A1 Subscriber side network element 4 4
B1 Network side network element 4 4
C1 SPA port 3/1/0 4
D1 SPA port 3/1/1 4
A2 Subscriber side network element 5 4
B2 Network side network element 5 5
