User Guide| LQ Series 4.0
Note: LQ units will draw up to 12 watts for a Partyline (depending on how many devices
are connected to the line).
20.6 Network quality settings
Default option is in bold
Bitrates
16, 32, 48, 64, 128 kbps
Packet
size
5, 10, 20, 40ms, 60ms
Jitter
buffer
200 1000ms,100 500ms60 200ms,40 - 100ms, 20 60ms, 5
60ms,0 60ms
20.7 Connectors
LQ Throw Down Units
2-wire (LQ-2W2) 4-wire (LQ-4W2)
4-wire + GPIO (LQ-
4WG2)
2 x etherCON (F) :
network 2 x 3 pin XLR-F:
audio
4 x etherCON (F): 2 for
network, 2 for audio
2 x etherCON (F) :
network 2 x DB-9M +
GPIO
LQ Rack Units
2-wire (LQ-
R2W4)
4-wire (LQ-
R4W8)
Combined
(LQ-R2W4-
4W4)
4-wire + GPIO
(LQ-R4WG8)
Combined GPIO
(LQ-
R2W4+4WG4)
2 x etherCON
(F) : network
4 x 3 pin XLR-
F4 x 3 pin
XLR-M
2 x etherCON
(F) : network
8 x etherCON
RJ45 F
2 x etherCON
(F) : network
4 x etherCON
RJ45 F4 x 3-
pin XLR-F
2 x etherCON
(F) : network
8 x DB-9M +
GPIO
2 x etherCON (F)
: network 4 x 3-
pin XLR-F4 x DB-
9M + GPIO
Page 176
