User Guide| LQ Series 4.0
This indicates that the device is continually booting and needs more power.
Consider using the supplied sleeve-locking connector cable or a higher Class PoE
switch.
2.3 Power 2-wire beltpacks from the Partyline
2-wire beltpacks take power from the Partyline. The maximum numbers are shown
in the table below.
LQ series
unit
Power supply
Number of beltpacks powered by the
Partyline
LQ 24 watts 150 mA (~5 beltpacks) per device
LQ
PoE (device draws up to
12 watts)
70 mA (~2 beltpacks) per device
LQ-R 60 watts
250 mA (~10 beltpacks per pair of ports,
max 20 per device)
2.4 Reboot system
The system will start its boot sequence immediately when power is applied. If you
need to reboot for any reason, either cycle the power or press all four direction keys
on the control panel on the front of the LQ unit at the same time.
The system can also be rebooted using the front panel menu screens: Menu >
Administration > Reboot and from the CCM: Device > General >
Maintenance > Reboot.
Page 21
