833-3577 CB-FALCON SYSTEM OPERATOR INTERFACE
® U.S. Registered Trademark
750-241
65-0296—01 M.S. 11-07
Fig. 119. User Preferences.
The Multiple Modbusâ„¢ Masters (share interface) checkbox
permits the Modbusâ„¢ network on the COM1 port to be shared
with another Modbusâ„¢ master (PLC, etc.). Special wiring is
required for this option to be implemented. Contact the
manufacturer for more information regarding this feature if
needed.
Table 43. Status Tables.
Name Table # Page #
CH 24 28
DHW 25 29
Burner Control 26 30
Demand and Modulation 27 31
Inlet High Limit 28 31
Fan 29 32
Pump 30 32
Flame Detection 31 33
Statistics 32 33
Stack Limit 33 34
Delta T Limit 34 34
Outdoor 35 35
CH Frost Protection 36 35
DHW Frost Protection 37 35
Lead Lag 38 36
Table 44. Other Tables.
Name Table # Page #
9-pin Conector Terminals 1 3
Lockout History 2 10
Alert Log 3 10
Trend Analysis Data 39 39
Digital I/O Data 40 40
Analog I/O Data 41 41
To Next Page
