Comtech EF Data LPOD - Page 122

LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Serial-based Remote Product Management MN-LPOD
5–14
Parameter Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to Query
(Target to
Controller)
Concise
Configuration
Status
N/A
26 bytes
Query only.
This is the concise version of the RCS query. Returns the configuration status of the unit, in the form
aa.aa;b;c;d;e;ff.ff;g;hhh, where:
aa.aa = attenuation in dB (ATT)
b = RF power amplifier state, 0 = Off, 1 = On (AMP)
c = mute state, 0 = un-muted, 1 = muted (MUT)
d = online status (ONL)
e = redundancy state and mode (ESW)
ff.ff = Attenuator offset in dB (AOF)
g = auto fault recovery mode (AFR)
hhh = External reference status, N/A = no external reference, 05M for 5 MHz, and 10M for a 10 MHz (See
Note)
Note: hhh will always be N/A if the internal reference oscillator option is not installed.
Example: CCS=aa.aa;b;c;d;e;ff.ff;g;hhh; ’cr’’lf’
CCS=
CCS?
CCS= aa.aa;b;c;d;e;
ff.ff;g;hhh
(See Description of
Arguments)
Concise RF Power
FET Current
Status
N/A
Length varies
depending on
number of
FETs installed
in the amplifier
Query only.
This is the concise version of the RFS query. Returns the RF Power FET Current status.
Example: CFS=xxx,xxx,x.x,x.x,……….,x.x,
CFS=
CFS?
CFS=x…..x
(See description of
RFS. Note that each
argument is
separated by a
comma.)
Circuit
Identification
CID=
48 bytes
Command or Query.
Sets or returns a 48-byte user-defined string that identifies or names the unit or station. The CID is entered as
one line, but it reads back from the unit as two 24-byte lines of data.
Default value: ------------------------
Examples:
<1/CID= Station #001--SSPA #01--’cr’
>0001/CID=
<1/CID?’cr’
>0001/CID=’cr’
Station #001’cr’
--SSPA #01--’cr’’lf’
CID=
CID?
CID*
CID?
CID=x…x
(See Description of
Arguments)
